Description
The Fluorometer1 Fluorometer is a very compact DNA and RNA concentration quantitative detection device, which can obtain highly accurate detection results with only 1~20 μL samples. With high detection sensitivity, wide range and short time, it is an ideal detection tool for scientific research laboratories.
Features
Fast: Quickly and accurately measures sample concentration within 3 to 5 seconds;
Low Sample Volume: Requires only 1–20 μL of sample to obtain accurate results;
Precise: High detection sensitivity makes it an effective tool for quantifying low-concentration nucleic acids and proteins;
Specific: Enables specific detection of dsDNA, ssDNA, RNA, and protein, with measurement results unaffected by other substances present in the sample;
Flexible: The fluorometer is compatible with quantification reagents from various brands.
Specifications
|
Cat.No. |
80571ES03 |
|
Sample Volume |
1~20 μL |
|
Sample Throughput |
1 |
|
Compatible Tube |
0.5 mL Transparent Thin Wall PCR Tube |
|
Test Time |
≤5 s/sample |
|
Linearity Range |
5 orders of magnitude |
|
Light Source |
LED |
|
Excitation Wavelength |
Blue 460-480 nm, Red 630-650 nm |
|
Emission Wavelength |
Green500-535 nm, Red670-710 nm |
|
Detector |
SiPMT |
|
Sensitivity |
dsDNA 0.01 ng/μL, ssDNA 0.05 ng/μL, RNA 0.25 ng/μL, microRNA 0.05 ng/μL |
|
Calibration |
2 points or 3 points |
|
Operation |
5 inches Touch screen |
|
Power |
DC5V，2A，10 W |
|
Working Environment |
15-30℃，<75%，Indoor use |
|
Dimension |
110*230*45.5 mm，0.5 Kg |
Components
|
Components No. |
Name |
80571ES03 |
|
80571 |
Qubit Nucleic Acid Quantifier Fluorometer (Single Channel) |
1 Set |
Instrument Side View
Notes
1. For your safety and health, wear a lab coat and disposable gloves while handling this product.
2. This product is intended for research use only.
